ELECTRICAL SAFETY TESTER USER MANUAL 15 19 SOURCE+ Terminal (only for Ground Bond Test) High current terminal for Ground Bond test. 20 Power Switch Press the power switch to turn on the tester. 21 SENSE+ Terminal Voltage Terminal for Ground Bond test.

View and Download GW Instek GOM-802 user manual online. Milli-Ohm Meter. GOM-802 Measuring Instruments pdf manual download.

22 SENSE- & Return Terminal SENSE- Terminal is a voltage terminal for Ground Bond test, and Return Terminal is for all test. 23 Ground Terminal Connect Ground terminal to the earth ground. 24 Fuse Holder with Voltage Selector To change AC source voltage, pull the fuse holder and rotate it to the proper value. 25 AC Inlet Connect the AC power line to the inlet. 26 Remote Interface The remote interface performs all the functions of PLC control. 27 RS232 Terminal D-SUB 9 pin connector, Input/Output connector for RS232.

28 GPIB Terminal Blue 24 connector, Input/Output connector for IEE-488. 29 Scanner Interface D-sub 9 pins female connector for scanner box. 30 High Voltage Output on rear panel High voltage output terminal. 31 Sense + Terminal on rear panel Voltage terminal for Ground Bond test. Digitizer Jr Software. 32 Source + Terminal on rear panel High current terminal for Ground Bond test. 33 Source - Terminal on rear panel High current terminal for Ground Bond test.

34 Sense - Terminal & Return Terminal on rear panel Sense - terminal is a voltage terminal for Ground Bond test, Return terminal is for all tests. *The instrument can be used together with scanner box of HSB-001-1 & HSB-001-2. *The Instrument can control one scanner box only. ELECTRICAL SAFETY TESTER USER MANUAL 16 5. OPERATION METHOD 5-1. Main Display LCD 1 ~ 0 1 A C W V = 5. 0 0 0 k V ＊ R E A D Y I m a x = 0 1.

0 0 m A T E S T ： 0 0 0. 0 s Table of parameters Storage Group/ Step: There are total 10 groups, and each group has 16 steps. The first number represents group while the second number represents step. 3:01 3 stands for group number, 01 stands for step number. The test mode of tester includes: ACW: AC Withstanding voltage test. DCW: DC Withstanding voltage test (only for GPT-715A/ GPI-735A/745A). I R: Insulation Resistance test (only for GPI-725A/GPI-735A /745A).
